Drilling Software Progress Report

By -
Last night I made some significant progress in PCB Drilling Software.

I added tracking of holes drilled, progress bar and ETA estimation.

Everything is coded in TCL/TK. The icon set used (modified) is from KDE's Oxygen Theme.

Of course, the screenshot:



The drillfile displayed is for the board with 6 Pinguino 4550 Light boards.


bb4now,
PMC
